803A trailer mounted power plant. Lamps

[grywitt]

These two screen shots are the only place I can find a part number for the on and on line lights on the sync box. I had one wire break off then touch the other side and cause a short and burn up the bulb. The box has spares but they are almost all beat up. I've searched with the part number but nothing pops up and the NSN number that AI gives me isn't for that light. Can anyone help me with any info or a source? The part number 13229E5764-2
XDS1 - XDS4 on the drawing

I can and will use one of the spare lamps that's in better shape if I have to buy it would like to use nice new ones. That bulb showed up as a short on my gen when the wire came off and touched the other one.



[peapvp]

Bulbs are 6S6/DC:

Many Times they use / in the bulb type

Satco Part Number: S3901
Those are 130V Bulbs with DC Bayonet socket ( /DC )



[grywitt]

Thank you



[grywitt]

That still doesn't look right.



[peapvp]

That still doesn't look right.

Correct, those are not S6S
Someone replaced the original S6S /DC with those. Check and see if the Lamp Code is embossed on those you got. You may need to solicit the help of a magnifying glass.

If they don't have anything embossed or printed on them, then they are finest Chinesium of recent vintage



[grywitt]

Well the part number on the actual machine is different than the TM I was looking at. I haven't found a source but I'm at least seeing thongs that look right in my search with this part number. I pulled out all 7 lamps and don't see any numbers anywhere.



[peapvp]

Well the part number on the actual machine is different than the TM I was looking at. I haven't found a source but I'm at least seeing thongs that look right in my search with this part number. I pulled out all 7 lamps and don't see any numbers anywhere.

The plaque shows the same bulbs S6SDC as the manual for DS5 to DS7



[Toolslinger]

Is that an assembly? I just ran across this page and scrolling down to the example drawing, it indicates a lamp, lens/housing, and what might be a little o-ring or such...

6210-00-900-9423 Light, Indicator



[Toolslinger]

Lamp is a T-2 Midget Flange. (that's a new one on me...)
Haven't found the lens housing yet...
Here's one of the OEM's you can dive deeper on info there...

DISCONTINUED | 18188360931553-15/32" PMI T-2 Midget Flange, Red Stovepipe Lens-Series181

Dialight Signals & Components is a leading provider of LED indication for PCBs, panels, traffic signals, vehicle and rail lighting. Browse our products, find a distributor, and contact us today.

www.dialightsignalsandcomponents.com



[peapvp]

Is that an assembly? I just ran across this page and scrolling down to the example drawing, it indicates a lamp, lens/housing, and what might be a little o-ring or such...

6210-00-900-9423 Light, Indicator

Dialight used to manufacture all of those Bulbs and sockets
The NSN you posted is for all parts shown on the page a complete assembly
a cousin of those look this here:

DIALIGHT 181-8836-0931-553 INDICATOR LIGHT RED


Dialight now makes only LED based Lights.

The Chinese are now making all the incadecent light bulbs like the ones you got currently installed



[grywitt]

The plaque shows the same bulbs S6SDC as the manual for DS5 to DS7

Right I'm needing ds1-ds4



[peapvp]

Right I'm needing ds1-ds4

6210-00-900-9423 (1034-D700-18, 12124-19, 13214E1391) Data


Dialight 181-8836-09-553
